ZK-TB21 TPA3116D2 bluetooth 5.0 Subwoofer Amplifier Board 50WX2+100W 2.1 Channel Power Audio Stereo Bass AMP COD

Compatibility

To confirm that this part fits your vehicle, please enter your vehicle's details below.

• Select
• Make:
• Select
• Submodel:
• Select
• Engine:

This part is compatible with vehicle(s).Show all compatible vehicles 1

• Year
• Make
• Model
• Submodel
• Trim
• Engine

Specifications:

Note:

Package Included:


The power supply with the board is very key, the selected power supply ripple must be small, ripple large power supply will lead to power amplifier bottom noise, there is a current sound.The higher the voltage, the higher the current, and the higher the power output. If you only have 12V 1A, you can have 3-4 inch speakers.If you are above 19V 5A, no problem with 8-10 inches, power must be highly valued.If the voltage is too low and the sound is amplified, it will easily cause sound distortion. If the current is too low and the horn cannot be brought up, the voltage will be pulled down, which will lead to abnormal operation or poor sound quality.It is recommended to use 18V19V24V power supply with current above 5A.If you only have 9V12V or 1A 2A power supply, you can also use it but with low power. When using it, choose the volume close to the maximum, which may cause distortion and affect the sound quality.
2. How to select speakers?
There are two audio input modes for this audio amplifier module: one is Bluetooth input and the other is AUX input. Bluetooth mode is preferred.Bluetooth can be connected in either mode.As long as the Bluetooth connection is successful, it is bluetooth mode, and bluetooth mode supports automatic back up.AUX insert is AUX mode when Bluetooth is disconnected.It should be note that the bluetooth connection of this module is disconnected when using AUX mode.
4. How to adjust the main volume?
R&L CHANNEL - BASS knob is for BASS, right-handed BASS enhancement, and left-handed BASS attenuation.When the knob is in the right-most position, it does not enhance or attenuate the bass.The R&L CHANNEL - TREBLE knob is used to control the TREBLE, with right-handed TREBLE enhancement and left-handed TREBLE attenuation.When the knob is in the middle, it does not enhance or attenuate the treble.Note when adjusting high and low sounds: when the TREBLE or BASS sounds are right-rotated to near maximum, if the sound distortion is distorted, the gain of the TREBLE or BASS sounds is too large. It is necessary to turn the TREBLE or BASS knob to the left to lower the gain or turn the MAIN-VOLUME knob on the right to the left to reduce the total VOLUME.
6. How to adjust the subwoofer?
The quality of sound is not only related to the power amplifier module, but also to the power supply, sound source and the whole sound system.Basically every link of the sound system will affect the sound quality, among which the main link is the audio transmission line, audio power supply, tone circuit, amplifier circuit, speakers and the surrounding environment.The sound quality is best when the sound source, power supply, amplifier module and the speaker are matched.
