30/120 Frames Camera Module High-speed Dynamic Capture Eye Tracker Recognition Distortion-free Fixed Focus GC0308 300,000 Pixel USB Driver-free COD

Compatibility

To confirm that this part fits your vehicle, please enter your vehicle's details below.

• Select
• Make:
• Select
• Submodel:
• Select
• Engine:

This part is compatible with vehicle(s).Show all compatible vehicles 1

• Year
• Make
• Model
• Submodel
• Trim
• Engine

Key Specifications:

Module No.	HBVCAM-1914S V44
Module Size	25mm x 12mm x 6mm±0.2MM
Temperature (Operation)
Temperature (Stable Image)
Assembly technique	SMT (ROSH)
Focus	Fixed
Object distance	30CM
Resolution	400LW/PH (Center)
PCB printing ink	Black
	USB 2.0
Power suuply	USB bus power
	DC 5V±5%
Maximum Power consumption	500mW
Operating system request
Sensor
Seneor Package
Maximum resolution	640*480
Sensitivity	3.0mv/ (lux-sec)
Pixel Size
Maximum Image Transfer Rate	MJPEG 320x240 128FPS / YUY2 320x240 128FPS
S/N Ratio	42 db
Max Dynamic Range	58 db
Shutter type	Electronic rolling shutter
AGC/AEC/Whiter balance	Auto
Output Formats	YUY2/MJPEG
Microphone	NO
Lens Construction	4P
F/No	2.8
EFL	2.6mm
FOV	50°
TV Distortion	<1.8%
Relative Illumination (Sensor)	70%
IR Filter
Module Package	Anti-electrostatic tray
Certifications	FCC/CE/ROSH

Package includes:

1 x Camera Module (optional)
